ARC2-PELY5306M2-C8V4M30
2U bifurcated and M.2 riser, 8 cm ribbon
Dual x16 at x8, x8 on the top and bottom slots, plus a middle x4 on a 30 cm ribbon to a 2280 M.2 socket. An 8 cm ribbon to the board on this build; the sheet also lists a 5 cm build.
| Riser slots | Two PCIe x16 (x8, x8 signals) + one x4 |
|---|---|
| M.2 | x4 to 2280 M.2, 30 cm ribbon |
| Generation | PCIe Gen4 compatible |
| Ribbon | 8 cm |
